Dellinger II FX-AM

(DISCONTINUED)

The Caparison Dellinger II FX-AM is a defined and focused no nonsense sonic leviathan.

The Light Ash and Maple composite body gives you a sweet airy tone that’s bright with a tight low end and loaded with a ton of sustain when played clean and a rampaging beast with a slightly scooped mid and razor sharp precision when you unleash the full power of the Caparison designed twin humbucker pickups and crank up the gain.

The Hipshot Fixed Bridge has solid steel saddles with a crisp string relief edge, eliminating dull tones, maximising string vibration and will stay solid no matter how hard you thrash. The beautiful simplicity of the design perfectly complimenting the sleek and dramatic design of the guitar.

The ebony fingerboard, now with signature Caparison clock inlays further enhances the slick aesthetics of the Dellinger II FX-AM and the luminous side fret marker dots are a practical and very cool addition. The addition of a 5-piece Maple & Walnut neck offers ultimate stability.



Caparison Dellinger Ⅱ FX-AM Dark Blue Matt
Dark Blue Matt
Caparison Dellinger Ⅱ FX-AM Dark Black Matt
Dark Black Matt
Caparison Dellinger Ⅱ FX-AM Dark Green Matt
Dark Green Matt


Body & Finish


Model Name: Dellinger FX-AM
Body Shape: Dellinger
Top: Light Ash
Back: Maple
Bridge: Hipshot Fixed .175
Head Top: Pro. Black
Neck Finish: Urethane Matt Finish
Body Finish: Dark Blue Matt,
Dark Black Matt,
Dark Green Matt,
Sky Blue Matt,
Burned Natural Matt
Hardware: Hipshot Black


Neck & Head


Neck Joint: Bolt-On
Neck Material: 5-Piece Maple/Walnut
Neck Grip: Caparison
Fingerboard: Ebony, Luminous Side Dots
Radius: R350 to R400
Scale Length: 648mm (25 1/2″)
Nut Width: 42mm
No. of Frets: 24
Fret Type: Jumbo, Nickel Silver
Depth, 1st Fret Approx. 21.0mm
Depth, 12th Fret Approx. 22.0mm
Nut: Graph Tech Black TUSQ
Position Inlay: Caparison Clock
Headstock: Devil’s Tail, Dellinger Logo
Head Angle: 15 Degrees
Tuners: Hipshot Grip-Lock Locking
Tuning: Standard C
Strings: RotoSound RH10 (.010-.052)

Electronics & Accessories


Neck Pickup: Caparison PH-F
Bridge Pickup: Caparison PH-R
Controls: CTS Master Volume,
Switchcraft 3-Way Toggle
Case: Reunion Blues Voyager case
